Lucioli 7MM Low Pressure System Rear (18 inch)

$169.99

Lucioli 7mm inner Tube Rear (18 inch)

Description

New tire inflation system for Offroad, Dual Sport, Crosscountry, Enduro and Hard Enduro

Specifications:

Working Pressure at medium load (average rider weight 75 kg at soft terrarin conditions.)

Rear Lucioli:
OFF Road with good traction:( 9 PSI)
Mixed Enduro Terrain: (6 PSI)
Hard Enduro Terrain:  (4 PSI)

Front Lucioli:
Starting from (5 TO 8 psi)

Recommendation for use
For Extreme Enduro, we recommend always using 2 tire stops/ rim locks/ safety bolts (do not cut any of them)

It is advisable to widen the rim holes to 9mm (from standard 8 mm) and chamfer the hole for ease of insertion of the valve and rim locks

A rim strip is not necessary

Please open your Lucioli as soon as they arrive, to return it to its original shape (it is shipped folded).

Installation Instructions
1) Lucioli should be installed with air valve out
2) Remove all current rim tape (they are not intended for use with enduro rims)
3) Insert Lucioli into the tire
4) Lubricate the inner diameter with a non-aggressive agent (petroleum jelly or water and soap)
5) Insert the inner tube valve and rim lock/ security bolt (the one closer to the valve) and secure by tightening the appropriate nuts
6) Using the lever, push the last rimlock into the hole (also from the inside)
7) CAUTION: by using the levers you risk cutting the chambers near rim locks
8) Inflate to min. 1 bar and tighten the bolt until you feel that the air expands the tube and the tire towards the rim, then tighten further by 1 turn (important: maximum torque 10nm)

18″ models fits the following sizes:
110/80/18, 120/80/18, 130/80/18, 140/80/18, 110/90/18, 120/90/18, 130/90/18, 140/90/18, 110/100/18, 120/100/18, 130/100/18, 140/100/18
